Industrial

Laboratory

Monitoring blue light radiation hazards in welding

Weathering ‘degradation studies’

UV sterilization

UV sterilization

Graphic arts

Virology

Photochemical matching

Microbial genetics

UV EPROM erasure

DNA research

Photo resists exposure

Biologic hoods

Curing of inks, adhesives and coatings

General laboratory use

Display

3 3/4 LCD display, maximum reading 39990.

Measurement Range

0-400 mW/cm2

Four Range Selectable

400 μW, 4000 μW, 40 mW, and 400mW

(1000 μW/cm2 = 1 mW/cm2)

UV Sensor Spectrum

bandpass 320 nm – 390 nm

Accuracy

±(4%FS + 2dgt)  Calibration under the standard UVA light & and compare; Special tested under the environment RF Field Strength less than 3V/M & frequency less than the 30 MHz only

Sensor Structure

Exclusive UV photo diode & UV color correction filter.

Sample Time

2.5 times / s.

Over Range Indication

‘OL’

Weight

325g (include battery)

Operating Temperature & Humidity

-10℃ to40℃(32℉-104℉)  0～70%Rh

Power Supply

DC 9V battery, 006P, MN 1604 (PP3) or equivalent.

Power Consumption

Approx. DC 2.7 mA

Dimension

165x50x32mm (photo detector)

160x78x43mm (meter body)
